GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment

Name: GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment
Brand: SANDING
Price: 3 USD

Quality GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment for sale

Brand Name : SANDING

Model Number : T9

Place of Origin : China

MOQ : 1 piece

Price : $3,500.00

Payment Terms : L/C, T/T

Supply Ability : 1 ~ 30 day

Delivery Time : 30 work day

Product name : GNSS RTK Receiver SANDING T9

Customized support : OEM, ODM, OBM

Application : Land Surveying

Function : GPS RTK Survey (Radio

Material : magnessium alloy

channels : 1598

GLONASS : L1C/A, L1P, L2C/A, L2P, L3

Voice : Multi-language switching

Contact Now

GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment

Overview

Products Descriptin

GNSSconfiguration	Number of channels	1598 channels
	BDS	BDS-2: B1I, B2I, B3I BDS-3: B1I, B3I, B1C, B2a, B2b
	GPS	L1,L1C,L2C,L2P,L5
	GLONASS	L1C/A,L1P,L2C/A,L2P,L3
	GALILEO	GIOVE-A,GIOVE-B,E1,E5A,E5B
	QZSS	L1C/A,L1 SAiF ,L2C,L5
	Positioning output rate	1Hz~20Hz
	Differential support	CMR,RTCM2.X,RTCM3.0,RTCM3.2
	Static format support	GNS, Rinex dual format static data
	RTK positioning accuracy	Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points)
	Static positioning accuracy	Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points) Elevation: ±(5+0.5×10¯6D) mm (D is the distance between the measured points)
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm;Elevation accuracy: ±0.50m+1ppm
	Initialization time	<10 seconds
	Initialization reliability	＞99.99%
	IMU tilt compensation	Additional horizontal pole tip uncertainty typically less than 10mm + 0.7 mm/° tilt down to 30° IMU tilt angle:0°~60°
communication	NFC Communication	Realizing close range (shorter than 10cm) automatic pair between receiver and controller (controller equipped NFC wireless communication module needed)
	WiFi	802.11b/g access point and client mode, can provide WiFi hotspot service
	Bluetooth	BLEBluetooth 4.0 standard, support for android, ios cellphone connection
	Wireless modem	Built-in radio, 1W/2W/3W switchable, typically work range can be 8KM Radio repeater
	I/O port	5PIN LEMO external power port + RS232, 7PIN external USB(OTG)+Ethernet 1 radio antenna interface
	frequency band:	410-470MHz
	Protocol	Farlink, Trim talk450s, SOUTH, HU ACE, Hi-tar get, Sa tel
User Interface	Buttons	One button operation
User Interface	Indicators	Four indicate lights
Electrical physical properties	battery	10000mAh, 7.4V
	Power Supply	9-28V DC, over voltag e protecon
	size	166mm x 96.1mm
	weight	1.3KG
	material	Magnesium aluminum alloy shell
Environmental characteristics	Dust and water release	IP67 standard, protected from long time immersion to depth of 1m
	Storag	-55°C~+85°C
	Operating	-45℃~70℃
Specification
System	model	H6
	operating system	Android 8.1
	CPU	Octa-core 2.0GHz
	RAM	4GB
	ROM	64GB
Communication	SIM frequencies	GSM: B2/B3/B5/B8 FDD-LTE :B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B25/B28 TDD-LTE B38/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 CDMA1x/CDMA2000 BC0
	WiFi(WLAN)	IEEE 802.11a/b/g/n, 2.4G/5G
	Bluetooth	V4.1
	NFC	Support NFC IGRS
	USB	Type-C, support OTG
Electrical	Battery	9200mAh
	Operating Time	15 Hrs
	Charging Time	240 Hrs
Physical	size	235mm90mm35mm
	Weight	520g
	Operating temperature	-20℃~+60℃

Products Description

GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment
